The HYB-3K-GXLS1 3kVA Hybrid Solar Inverter is designed to deliver reliable and efficient solar power for modern homes and small offices. With advanced MPPT technology, it intelligently manages energy by automatically switching between solar panels, battery, and grid power, ensuring an uninterrupted electricity supply.
Its transformer-less design improves efficiency while reducing energy losses. The compact wall-mountable structure makes installation simple and ideal for residential solar setups. With smart monitoring and high performance, this inverter helps reduce electricity costs while maximizing solar energy usage.
Available through Narayana Solar – one of the trusted solar solution providers in India, this inverter offers reliable backup and smart energy management for everyday power needs.
Key Features
-
Advanced MPPT technology for maximum solar power generation
-
Automatic switching between solar, battery, and grid power
-
Transformer-less design for higher efficiency
-
Compact wall-mountable design for easy installation
-
Compatible with Lithium-ion and Lead-acid batteries
-
Remote monitoring support (WiFi / GPRS / Bluetooth / 4G / LAN)
-
Silent operation with low noise
-
5-year manufacturer warranty
Product Specifications
| Particular | Description |
|---|---|
| Model | HYB-3K-GXLS1 |
| Inverter Technology | MPPT |
| Phase | Single Phase |
| Mounting Type | Wall-Mountable |
| Transformer Type | Transformerless |
| Battery Support | Lithium-ion & Lead-acid |
| Warranty | 5 Years |
| Remote Monitoring | GPRS / WiFi / Bluetooth / 4G / LAN |
| Display | LCD + LED |
Technical Specifications
| Parameter | Rating |
|---|---|
| Rated Output Power | 3000 W |
| Max Charging Current | 70 A |
| MPPT Efficiency | >99% |
| Max PV Input Power | 3900 W |
| MPPT Voltage Range | 150V – 425V |
| Charge Controller | PWM Technology |
| Weight | 17 kg |
| Operating Temperature | -40°C to 60°C |
| Noise Level | <30 dB |
Safety Standards:
IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 21700, OVE-Richtlinie R25, VDE-AR-N 4105
